规格 Size mmJ | 电缆外径 cable diameter mm | 计算重fit Approx weight kg/km | 规格 Size mm' | 电缆外径 cable diameter mm | 计算重量 Approx weight kg/km |
1 x2x0.75 | 12.2±1.0 | 181 | 1 x2x1.0 | 12.6±1.0 | 193 |
2x2x0.75 | 17.0±1.0 | 295 | 2x2x1.0 | 17.8±1.0 | 321 |
3x2x0.75 | 18.0±1.0 | 338 | 3x2x1.0 | 18.7±1.0 | 371 |
4x2x0.75 | 19.0±1.0 | 392 | 4x2x1.0 | 20.6±1.5 | 432 |
5x2x0.75 | 21.5±1.5 | 448 | 5x2 x 1.0 | 22.6±1.5 | 497 |
7x2x0.75 | 23.3±1.5 | 533 | 7x2x1.0 | 24.5±1.5 | 597 |
10x2x0.75 | 29.5±1.5 | 731 | 10x2x1.0 | 31.0±1.5 | 822 |
12x2x0.75 | 30.3±1.5 | 802 | 12x2x1.0 | 32.1 ±1.5 | 906 |
14x2x0.75 | 31.9±1.5 | 885 | 14x2x1.0 | 33.5±1.5 | 1003 |
16x2x0.75 | 33.9±1.5 | 974 | 16x2x1.0 | 35.6±1.5 | 1107 |
19x2x0.75 | 35.7±1.5 | 1091 | 19x2x1.0 | 37.5±1.5 | 1284 |
24x2x0.75 | 41.7±2.0 | 1487 | 24x2x1.0 | 44.0±2.0 | 1690 |
27x2x0.75 | 43.1 ±2.0 | 1587 | 27x2x1.0 | 45.3±2.0 | 1809 |
30x2x0.75 | 44.7±2.0 | 1707 | 30x2x1.0 | 47.1±2.0 | 1950 |
37x2x0.75 | 48.2±2.0 | 1985 | 37x2x1.0 | 50.9±2.0 | 2331 |
1 x2x1.5 | 13.6±1.0 | 257 | 1 x2x2.5 | 14.6±1.0 | 300 |
2x2x1.5 | 19.6±1.0 | 386 | 2x2x2.5 | 21.7±1.5 | 469 |
3x2x1.5 | 20.8±1.5 | 453 | 3x2x2.5 | 22.8±1.5 | 562 |
4x2x1.5 | 22.6±1.5 | 534 | 4x2x2.5 | 25.0±1.5 | 671 |
5x2x1.5 | 24.6±1.5 | 620 | 5x2x2.5 | 27.5±1.5 | 786 |
7x2x1.5 | 26.9±1.5 | 754 | 7x2x2.5 | 30.1±1.5 | 972 |
10x2x1.5 | 34.3±1.5 | 1049 | 10x2x2.5 | 38.3±1.5 | 1405 |
12x2x1.5 | 35.3±1.5 | 1164 | 12x2x2.5 | 39.6±1.5 | 1654 |
14x2x1.5 | 37.1 ±1.5 | 1337 | 14x2x2.5 | 41.9±2.0 | 1845 |
16x2x1,5 | 39.4±1,5 | 1479 | 16x2x2.5 | 43.8±2.0 | 2046 |
19x2x1.5 | 41.7±2.0 | 1756 | 19x2x2.5 | 46.5±2.0 | 2317 |
24x2x1.5 | 48.8±2.0 | 2245 | 24x2x2.5 | 55.0±2.0 | 2965 |
27x2x1.6 | 50.4±2.0 | 2413 | 27x2x2.5 | 56.5±2.0 | 3205 |
30x2x1.5 | 52.1 ±2.0 | 2606 | 30x2x2.5 | 58.6±2.0 | 3476 |
37x2x1.5 | 56.6±2.0 | 3058 | 37x2x2.5 | 63.4±2.5 | 4109 |
