规格 Size mm' | 电缆外径 cable diameter mm | 计算匝fit Approx weight kg/km | 规格 Size mm' | 电缆外径 cable diameter mm | 计算匝量 Approx weight kg/km |
1 x2x0.75 | 10.8±1.0 | 170 | 1 x2x1.0 | 11.8±1.0 | 210 |
2x2x0.76 | 14.5±1.0 | 259 | 2x2x1.0 | 16.2±1.0 | 284 |
3x2x0.75 | 15.4±1.0 | 295 | 3x2x1.0 | 16.9±1.0 | 327 |
4x2x0.75 | 16.5±1.0 | 341 | 4x2x1.0 | 18.4±1.0 | 380 |
5x2x0.75 | 17.9±1.0 | 389 | 5x2x1.0 | 20.3±1.0 | 436 |
7x2x0.75 | 19.6±1.0 | 462 | 7x2x1.0 | 22.2±1.5 | 522 |
10x2x0.75 | 24.7±1.5 | 628 | 10x2x1.0 | 27.7±1.5 | 714 |
12x2x0.75 | 25.4±1.5 | 688 | 12x2x1.0 | 28.5±1.5 | 788 |
14x2x0.75 | 26.7±1.5 | 759 | 14x2x1.0 | 30.0±1.5 | 871 |
16x2x0.75 | 28.1 ±1.5 | 834 | 16x2x1.0 | 31.8±1.5 | 961 |
19x2x0.75 | 29.6±1.5 | 933 | 19x2x1.0 | 33.3±1.5 | 1079 |
24x2x0.75 | 34.4±1.5 | 1158 | 24x2x1.0 | 39.1±1.5 | 1384 |
27x2x0.75 | 35.5±1.5 | 1281 | 27x2x1.0 | 40.1±1.5 | 1487 |
30x2x0.75 | 36.6±1.5 | 1379 | 30x2x1.0 | 41.8±2.0 | 1689 |
37x2x0.75 | 39.5±1.5 | 1693 | 37x2x1.0 | 45.1 ±2.0 | 1971 |
1x2x1.5 | 12.2±1.0 | 243 | 1x2x2.5 | 13.3±1.0 | 285 |
2x2x1.5 | 17.0±1.0 | 347 | 2x2x2.5 | 19.1±1.0 | 428 |
3x2x1.5 | 18.0±1.0 | 406 | 3x2x2.5 | 20.3±1.0 | 512 |
4x2x1.5 | 19.8±1.0 | 478 | 4x2x2.5 | 22.1 ±1.5 | 611 |
5x2x1.5 | 21.5±1.5 | 553 | 5x2x2.5 | 24.2±1.5 | 714 |
7x2x1.5 | 23.3±1.5 | 672 | 7x2x2.5 | 26.3±1.5 | 883 |
10x2x1.5 | 29.411.5 | 930 | 10x2x2.5 | 33.4±1.5 | 1234 |
12x2x1.6 | 30.4±1.5 | 1033 | 12x2x2.5 | 34.6±1.5 | 1423 |
14x2x1.5 | 32.0±1.5 | 1150 | 14x2x2.5 | 36.4±1.5 | 1592 |
16x2x1.5 | 33.7±1.5 | 1274 | 16x2x2.5 | 38.5±1.5 | 1854 |
19x2x1.5 | 35.7±1.5 | 1481 | 19x2x2.5 | 40.8±1.5 | 2101 |
24x2x1.5 | 41.8±2.0 | 1941 | 24x2x2.5 | 48.0±2.0 | 2683 |
27x2x1.5 | 42.8±2.0 | 2089 | 27x2x2.5 | 48.9±2.0 | 2902 |
30x2x1.5 | 44.4±2.0 | 2259 | 30x2x2.5 | 50.9±2.0 | 3147 |
37x2x1.5 | 48.1±2.0 | 2710 | 37x2x2.5 | 54.9±2.0 | 3721 |
