規格 | 电缆外经 | 计算质量 | 規格 | 电缆外役 | 计算1ft量 |
Size | cable diameter | Approx weight | Size | cable diameter | Approx weight |
mm' | mm | kg/km | mm' | mm | kg/km |
1 x2x0.75 | 11.4±1.0 | 155 | 1 x2x1.0 | 12.0±1.0 | 167 |
2x2x0.75 | 16.1±1.0 | 280 | 2x2x1.0 | 16.7±1.0 | 304 |
3x2x0.75 | 16.9±1.0 | 321 | 3x2x1.0 | 17.7 ±1.0 | 352 |
4x2x0.75 | 18.4±1.0 | 372 | 4x2x1.0 | 18.7±1.0 | 411 |
5x2x0.75 | 20.2±1.0 | 426 | 5x2x1.0 | 21.2±1.5 | 473 |
7x2x0.76 | 21.9±1.5 | 508 | 7x2x1.0 | 22.9 ±1.5 | 569 |
10x2x0.75 | 27.6±1.5 | 694 | 10x2x1.0 | 29.0 ±1.5 | 782 |
12x2x0.75 | 28.4±1.5 | 763 | 12x2x1.0 | 29.8 ±1.5 | 864 |
14x2x0.75 | 29.9±1.5 | 843 | 14x2x1.0 | 31.4±1.5 | 958 |
16x2x0.75 | 31.7±1.5 | 929 | 16x2x1.0 | 33.1 ±1.5 | 1058 |
19x2x0.75 | 33.2±1.5 | 1041 | 19x2x1.0 | 34.8 ±1.5 | 1191 |
24x2x0.75 | 38.9±1.5 | 1336 | 24x2x1.0 | 40.9±2.0 | 1612 |
27x2x0.75 | 39.9±1.5 | 1433 | 27x2x1.0 | 42.1 ±2.0 | 1729 |
30x2x0.75 | 41.6±2.0 | 1629 | 30x2x1.0 | 43.7±2.0 | 1865 |
37x2x0.75 | 44.9±2.0 | 1897 | 37x2x1.0 | 47.3 ±2.0 | 2181 |
1 x2x1.5 | 13.0±1.0 | 226 | 1 x2x2.5 | 13.9±1.0 | 268 |
2x2x1.5 | 18.1 ±1.0 | 366 | 2x 2x2.5 | 20.1 ±1.5 | 446 |
3x2x1.5 | 19.5±1.0 | 431 | 3x2x2.5 | 21.5±1.5 | 536 |
4x2x1.5 | 21.2±1.5 | 509 | 4x2x2.5 | 23.5 ±1.5 | 641 |
5x2x1.5 | 23.1 ±1.5 | 590 | 5x2x2.5 | 25.6±1.5 | 752 |
7x2x1.5 | 25.2±1.5 | 720 | 7x2x2.5 | 28.0±1.5 | 932 |
10x2x1,5 | 31.9±1.5 | 999 | 10x2x2.5 | 35.8 ±1.5 | 1344 |
12x2x1.5 | 33.0±1.5 | 1113 | 12x2x2.5 | 36.9 ±1.5 | 1506 |
14x2x1.5 | 34.7±1.5 | 1241 | 14x2x2.5 | 39.0 ±1.5 | 1687 |
16x2x1.5 | 36.8±1.5 | 1415 | 16x2x2.5 | 41.3±2.0 | 1964 |
19x2x1.5 | 38.8 ± 1.5 | 1599 | 19x2x2.5 | 43.3±2.0 | 2227 |
24x2x1.5 | 45.4±2.0 | 2096 | 24x2x2.5 | 51.2±2.0 | 2845 |
27x2x1.5 | 46.5±2.0 | 2259 | 27x2x2.5 | 52.2±2.0 | 3080 |
30x2x1.5 | 48.5±2.0 | 2497 | 30x2x2.5 | 54.3 ±2.0 | 3344 |
37x2x1.5 | 52.4±2.0 | 2935 | 37x2x2.5 | 59.0±2.0 | 3959 |
