规格 Size mm' | 电缆外径 cable diameter mm | 计算重量 Approx weight kg/km | 规格 Size mm' | 电煙外径 cable diameter mm | 计算重量 Approx weight kg/km |
1x2x0.75 | 9.5 ±1.0 | 122 | 1x2x1.0 | 9.9 ±1.0 | 133 |
2x2x0.75 | 14.5±1.0 | 211 | 2x2x1.0 | 15.1±1.0 | 230 |
3x2x0.75 | 15.3±1.0 | 251 | 3x2x1.0 | 16.0±1.0 | 281 |
4x2x0.75 | 16.7±1.0 | 299 | 4x2x1.0 | 17.7±1.0 | 335 |
5x2x0.75 | 18.4±1.0 | 348 | 5x2x1.0 | 19.3±1.0 | 392 |
7x2x0.75 | 20.1 ±1.5 | 425 | 7x2x1.0 | 21.2±1.5 | 483 |
10x2x0.75 | 25.9 ±1.5 | 596 | 10x2x1.0 | 27.3±1.5 | 680 |
12x2x0.75 | 26.9 ±1.5 | 663 | 12x2x1.0 | 28.2±1.5 | 760 |
14x2x0.75 | 28.3 ±1.5 | 739 | 14x2x1.0 | 29.9±1.5 | 850 |
16x2x0.75 | 30.0 ±1.5 | 820 | 16x2x1.0 | 31.5±1.5 | 945 |
19x2x0.75 | 31.6±1.5 | 929 | 19x2x1.0 | 33.4±1.5 | 1074 |
24x2x0.75 | 37.4 ±1.5 | 1171 | 24x2x1.0 | 39.5±1.5 | 1356 |
27x2x0.75 | 38.2 ±1.5 | 1265 | 27x2x1.0 | 40.4±2.0 | 1555 |
30x2x0.75 | 39.8 ±1.5 | 1373 | 30x2x1.0 | 42.1 ±2.0 | 1686 |
37x2x0.75 | 43.2±2.0 | 1716 | 37x2x1.0 | 45.6±2.0 | 1993 |
1x2x1.5 | 10.9±10 | 159 | 1x2x2.5 | 194 | |
2x2x1.5 | 16.5±1-0 | 291 | 2x2x2.5 | 18.4±1° | 360 |
3x2x1.5 | 17.7 + 1.0 | 353 | 3x2x2.5 | 19.7±10 | 452 |
4x2x1.5 | 19.3±1-0 | 426 | 4x2x2.5 | 21.6±1.5 | 551 |
5x2x1.5 | 21.4±1.5 | 502 | 5x2x2.5 | 23.9±1 5 | 656 |
7x2x1.5 | 23.5±1.5 | 626 | 7x2x2.5 | 26.2±1.5 | 830 |
10x2x1.5 | 30.2±1.5 | 888 | 10x2x2.5 | 34.1±1.5 | 1184 |
12x2x1.5 | 31.4 + 1.5 | 996 | 12x2x2.5 | 35.2±1.5 | 1343 |
14x2x1.5 | 33.1+1.5 | 1122 | 14x2x2.5 | 37.2±15 | 1517 |
16x2x1.5 | 35.1 ±1.5 | 1253 | 16x2x2.5 | 39.5±1.5 | 1787 |
19x2x1.5 | 37.2 + 1.5 | 1431 | 19x2x2.5 | 41.7+1.5 | 2045 |
24x2x1.5 | 44.0±2.0 | 1908 | 24x2x2.5 | 49.5+2.0 | 2587 |
27x2x1.5 | 45.2±2.0 | 2069 | 27x2x2.5 | 50.8±2.0 | 2818 |
30x2x1.5 | 46.8+2.0 | 2250 | 30x2x2.5 | 52.7+2.0 | 3076 |
37x2x1.5 | 51.0±2.0 | 2674 | 37x2x2.5 | 57.3+2.0 | 3676 |
