规格 Size mm' | 电缆外径 cable diameter mm | 计算重fit Approx weight kg/km | 規格 Size mm' | 电缆外径 cable diameter mm | 计算匝量 Approx weight kg/km |
1x2x0.75 | 9.1 ±0.8 | 101 | 1x2x1.0 | 9.5 ±1.0 | 111 |
2x2x0.75 | 13.2±1.0 | 169 | 2x2x1.0 | 14.0±1.0 | 199 |
3x2x0.75 | 14.4±1.0 | 238 | 3x2x1.0 | 15.1±1.0 | 266 |
4x2x0.75 | 15.7±1.0 | 283 | 4x2x1.0 | 16.4±1.0 | 318 |
5x2x0.75 | 17.1±1.0 | 330 | 5x2x1.0 | 18.1±1.0 | 372 |
7x2x0.75 | 18.8±1.0 | 404 | 7x2x1.0 | 19.7±1.0 | 460 |
10x2x0.75 | 24.2± 1.5 | 566 | 10x2x1.0 | 25.3±1.5 | 647 |
12x2x0.75 | 24.9± 1.5 | 631 | 12x2x1.0 | 26.4±1.5 | 724 |
14x2x0.75 | 26.4± 1.5 | 704 | 14x2x1.0 | 27.7±1.5 | 812 |
16x2x0.75 | 27.8± 1.5 | 782 | 16x2x1.0 | 29.4±1.5 | 904 |
19x2x0.75 | 29.5±1.5 | 887 | 19x2x1.0 | 31.0±1.5 | 1029 |
24x2x0.75 | 34.7±1.5 | 1117 | 24x2x1.0 | 36.6±1.5 | 1296 |
27x2x0.75 | 35.6±1.5 | 1209 | 27x2x1.0 | 37.4±1.5 | 1407 |
30x2x0.75 | 36.9±1.5 | 1313 | 30x2x1.0 | 39.2±1.5 | 1531 |
37x2x0.75 | 40.0± 2.0 | 1642 | 37x2x1.0 | 42.5±2.0 | 1912 |
1 x2x1.5 | 10.3±1.5 | 136 | 1x2x2.5 | 11.4±1.0 | 170 |
2x2x1.5 | 15.5±1.0 | 256 | 2x2x2.5 | 17.3±1.0 | 308 |
3x2x1.5 | 16.4±1.0 | 335 | 3x2x2.5 | 18.3±1.0 | 430 |
4x2x1.5 | 18.1±1.0 | 405 | 4x2x2.5 | 20.2±1.5 | 527 |
5x2x1.5 | 20.0± 1.5 | 478 | 5x2x2.5 | 22.3±1.5 | 627 |
7x2x1.5 | 21.8± 1.5 | 598 | 7x2x2.5 | 24.3±1.5 | 797 |
10x2x1.5 | 28.2±1.5 | 847 | 10x2x2.5 | 31.6±1.5 | 1134 |
12x2x1.5 | 29.1 ±1.5 | 955 | 12x2x2.5 | 32.6±1.5 | 1290 |
14x2x1.5 | 30.7±1.5 | 1075 | 14x2x2.5 | 34.5±1.5 | 1459 |
16x2x1.5 | 32.5±1.5 | 1201 | 16x2x2.5 | 36.6±1.5 | 1637 |
19x2x1.5 | 34.5±1.5 | 1374 | 19x2x2.5 | 38.6±1.5 | 1969 |
24x2x1.5 | 40.8±2.0 | 1827 | 24x2x2.5 | 45.9±2.0 | 2488 |
27x2x1.5 | 41.7±2.0 | 1984 | 27x2x2.5 | 46.9±2.0 | 2715 |
30x2x1.5 | 43.4±2.0 | 2160 | 30x2x2.5 | 48.9±2.0 | 2965 |
37x2x1.5 | 47.0±2.0 | 2571 | 37x2x2.5 | 53.2±2.0 | 3550 |
