规格 | 电境外径 | 计算重It | 規格 | 电缆外径 | 计算重量 | 规格 | 电缆外筏 | 计算重量 |
Size | cable diameter | Approx weight | Size | cable diameter | Approx weight | Size | cable diameter | Approx weight |
mm' | mm | kgfkm | mm： | mm | kg/km | mm' | mm | kg/km |
1x1 | 8.4±0.8 | 100 | 2x1 | 12.3±1.0 | 174 | 3x1 | 12.9±1.0 | 201 |
1x1.5 | 8.6±0.8 | 110 | 2x1.5 | 12.7±1.0 | 196 | 3x1.5 | 13.3±1.0 | 259 |
1x2.5 | 9.3±0.8 | 129 | 2x2.5 | 13.6±1.0 | 268 | 3x2.5 | 14.5±1.0 | 327 |
1x4 | 9.8±0.8 | 154 | 2x4 | 14.9±1.0 | 323 | 3x4 | 15.8±1.0 | 401 |
1x6 | 10.4±1.0 | 185 | 2x6 | 16.2±1.0 | 391 | 3x6 | 17.3±1.0 | 494 |
1x10 | 11.8±1.0 | 242 | 2x10 | 18.9±1.0 | 518 | 3x10 | 20.1 ±1.5 | 667 |
1x16 | 12.8±1.0 | 321 | 2x16 | 21.3±1.5 | 691 | 3x16 | 22.5±1.5 | 906 |
1x25 | 14.7±1.0 | 484 | 2x25 | 24.8 ±1.5 | 978 | 3x25 | 26.7±1.5 | 1302 |
1x35 | 16.1 ±1.0 | 610 | 2x35 | 27.8 ±1.5 | 1246 | 3x35 | 29.7±1.5 | 1654 |
1x50 | 17.9±1.0 | 793 | 2x50 | 31.0 ±1.5 | 1634 | 3x50 | 33.1 ±1.5 | 2200 |
1 x70 | 20.5±1.5 | 1042 | 2x70 | 35.5±1.5 | 2166 | 3x70 | 38.4±1.5 | 3072 |
1 x95 | 22.8 ±1.5 | 1331 | 2x95 | 40.5 ±2.0 | 2873 | 3x95 | 43.4±2.0 | 3959 |
1 x120 | 24.5 ±1.5 | 1626 | 2x120 | 44.1 ±2.0 | 3514 | 3x120 | 47.4±2.0 | 4815 |
1 x150 | 26.8 ±1.5 | 1982 | 一 | - | — | 3x150 | 52.1 ±2.0 | 5907 |
1x185 | 39.3±1-5 | 2403 | - | 一 | — | 3x185 | 57.8±2.0 | 7267 |
1x240 | 32.9 ±1.5 | 3026 | — | — | ||||
1x300 | 35.9 ±1-5 | 3693 | - | ■ | — | 一 | - | — |
4x1 | 14.0±1.0 | 275 | 4x1.5 | 14.6±1.0 | 302 | 4x2.5 | 15.1±1.0 | 374 |
5x1 | 15.0±1.0 | 303 | 5x1.5 | 15.5±1-0 | 348 | 5x2.5 | 17.0±1.0 | 447 |
7x1 | 16.0±1.0 | 360 | 7x1.5 | 16.5±1.0 | 431 | 7x2.5 | 18.4±1.0 | 545 |
10x1 | 20.0 ±1.5 | 505 | 10x1.5 | 20.9 ±1-5 | 591 | 10x2.5 | 23.2 ±1.5 | 738 |
12x1 | 20.7±1.5 | 554 | 12x1.5 | 21.6±1.5 | 636 | 12x2.5 | 23.8±1-5 | 823 |
14x1 | 21.7±1.5 | 595 | 14x1.5 | 22.5 ±1-5 | 706 | 14x2.5 | 25.0±1.5 | 939 |
16x1 | 22.6 ±1.5 | 654 | 16x1.5 | 23.9 ±1.5 | 798 | 16x2.5 | 26.3±1.5 | 1041 |
19x1 | 24.0 ±1.5 | 751 | 19x1.5 | 24.9 ±1.5 | 897 | 19x2.5 | 2 乙 7±1.5 | 1158 |
24x1 | 27.6 ±1.5 | 933 | 24x1.5 | 29.1 ±1-5 | 1097 | 24x2.5 | 32.4 ±1.5 | 1453 |
27x1 | 28.3 ±1.5 | 979 | 27x1.5 | 29.6 ±1.5 | 1182 | 27x2.5 | 33.0±1.5 | 1601 |
30x1 | 29.3±1.5 | 1057 | 30x1.5 | 30.7 ±1-5 | 1303 | 30x2.5 | 34.4 ±1-5 | 1738 |
33x1 | 30.2 ±1-5 | 1161 | 33x1.5 | 31.8±1.5 | 1406 | 33x2.5 | 35.5 ±1-5 | 1853 |
37x1 | 31.4 ±1.5 | 1262 | 37x1.5 | 33.1 ±15 | 1508 | 37x2.5 | 36.8±1.5 | 2031 |
