规格 Size mm' | 电缆外径 cable diameter mm | 计算重跟 Approx weight kg/km | 规格 Size mm' | 电缆外径 cable diameter mm | 计算ar量 Approx weight kg/km |
2x0.75 | 10.8±1.0 | 147 | 2x1 | 12.3±1.0 | 174 |
3x0.75 | 11.2±1.0 | 168 | 3x1 | 12.9±10 | 201 |
4x0.75 | 11.9±1.0 | 201 | 4x1 | 14.0±10 | 275 |
5x0.75 | 12.7±1.0 | 221 | 5x1 | 15.0±10 | 303 |
7x0.75 | 14.011.0 | 293 | 7x1 | 16.0±1.0 | 360 |
10x0.75 | 16.8±1.0 | 404 | 10x1 | 20.0±1.5 | 505 |
12x0.75 | 17.2±1.0 | 442 | 12x1 | 20.7±1.5 | 554 |
14x0.75 | 17.9±1.0 | 472 | 14x1 | 21.7±1.5 | 595 |
16x0.75 | 18.7±1.0 | 517 | 16x1 | 22.6±1.5 | 654 |
19x0.75 | 19.5± 1.0 | 592 | 19x1 | 24.0 — 5 | 751 |
24x0.75 | 22.3±1.5 | 728 | 24x1 | 27.6±1.5 | 933 |
27x0.75 | 22.7±1.5 | 763 | 27x1 | 28.3±1.5 | 979 |
30x0.75 | 23.4±1.5 | 822 | 30x1 | 29.3±1.5 | 1057 |
33x0.75 | 24.2±1.5 | 902 | 33x1 | 30.2 ±1.5 | 1161 |
37x0.75 | 25.0±1.5 | 979 | 37x1 | 31.4±1.5 | 1262 |
2x1.5 | 12.7±10 | 196 | 2x2.5 | 13.6±1。 | 268 |
3x1.5 | 13.3±10 | 259 | 3x2.5 | 14.5±10 | 327 |
4x1.5 | 14.6±10 | 302 | 4x2.5 | 15.1±10 | 374 |
5x1.5 | 15.5±10 | 348 | 5x2.5 | 17.0±10 | 447 |
7x1.5 | 16.5±1-0 | 431 | 7x2.5 | 18.4±10 | 545 |
10x1.5 | 20.9 ±1.5 | 591 | 10x2.5 | 23.2±15 | 738 |
12x1.5 | 21,6±1・5 | 636 | 12x2.5 | 23.8±1.5 | 823 |
14x1.5 | 22.5 ±1.5 | 706 | 14x2.5 | 25.0±1.5 | 939 |
16x1.5 | 23.9 ±15 | 798 | 16x2.5 | 26.3±1.5 | 1041 |
19x1.5 | 24.9 ±1-5 | 897 | 19x2.5 | 27.7±1.5 | 1158 |
24x1.5 | 29.1 ±1-5 | 1097 | 24x2.5 | 32.4±1.5 | 1453 |
27x1.5 | 29.6 ±1.5 | 1182 | 27x2.5 | 33.0± 1.5 | 1601 |
30x1.5 | 30.7 ±1.5 | 1303 | 30x2.5 | 34.4±1.5 | 1738 |
33x1.5 | 31.8±1.5 | 1406 | 33x2.5 | 35.5±1.5 | 1853 |
37x1.5 | 33.1 ±1-5 | 1508 | 37x2.5 | 36.811.5 | 2031 |
