规格 Size mm' | 电缆外径 cable diameter mm | 计算重最 Approx weight kg/km | 规格 Size mm' | 电煙外径 cable diameter mm | 计算重量 Approx weight kg/km |
2x0.75 | 9.4 ±0.8 | 121 | 2x1 | 11.1±1.o | 155 |
3x0.75 | 9.8 ±0.8 | 139 | 3x1 | 11.8±1.0 | 179 |
4x0.75 | 10.3± 1.0 | 164 | 4x1 | 12.6±1.0 | 214 |
5x0.75 | 10.9±1.0 | 181 | 5x1 | 13.4±1.0 | 269 |
7x0.75 | 11-5±1.0 | 215 | 7x1 | 14.6± 1.0 | 318 |
10x0.75 | 14.2± 1.0 | 326 | 10x1 | 17.8±1.0 | 444 |
12x0.75 | 14.5±1.0 | 357 | 12x1 | 18.2±1.0 | 487 |
14x0.75 | 15.0±1.0 | 381 | 14x1 | 19.2± 1-0 | 521 |
16x0.75 | 15.6± 1.0 | 417 | 16x1 | 20.4±1.5 | 573 |
19x0.75 | 16.2± 1.0 | 478 | 19x1 | 21.2±15 | 657 |
24x0.75 | 18.3*1.0 | 582 | 24x1 | 24.4± L5 | 814 |
27x0.75 | 18.6± 1.0 | 612 | 27x1 | 25.0±L5 | 854 |
30x0.75 | 19.21.0 | 660 | 30x1 | 26.0*15 | 921 |
33x0.75 | 19.8± 1.0 | 724 | 33x1 | 26.8 士 15 | 1012 |
37x0.75 | 20.4± 1.5 | 787 | 37x1 | 27.8± 1.5 | 1099 |
2x1.5 | 11.7±1.0 | 176 | 2x2.5 | 12.7±1.0 | 217 |
3x1.5 | 12.2±1.0 | 207 | 3x2.5 | 13.3±10 | 299 |
4x1.5 | 13.2± 1.0 | 272 | 4x2.5 | 14.6± 1.0 | 341 |
5x1.5 | 14.3± 1.0 | 312 | 5x2.5 | 15.5±1.0 | 408 |
7x1.5 | 15.5± 1.0 | 387 | 7x2.5 | 17.0±1.0 | 497 |
10x1.5 | 18.9±1.0 | 527 | 10x2.5 | 21.0±1.5 | 669 |
12x1.5 | 19.6±1.0 | 567 | 12x2.5 | 21.6±1.5 | 747 |
14x1.5 | 20.4*1.5 | 628 | 14x2.5 | 22.9±1.5 | 852 |
16x1.5 | 21.2±1.5 | 710 | 16x2.5 | 23.9±1.5 | 945 |
19x1.5 | 22.3± 1.5 | 798 | 19x2.5 | 25.1±1.5 | 1051 |
24x1.5 | 25.9 ±1.5 | 972 | 24x2.5 | 29.2±1.5 | 1315 |
27x1.5 | 26.3*1.5 | 1048 | 27x2.5 | 29.7± 1.5 | 1450 |
30x1.5 | 27.3*1.5 | 1156 | 30x2.5 | 31.0± 1.5 | 1574 |
33x1.5 | 28.4±1.5 | 1247 | 33x2.5 | 32.0± 1.5 | 1678 |
37x1.5 | 29.3 ±1.5 | 1337 | 37x2.5 | 33.O±1.5 | 1839 |
