規格 Size mm' | •电煙外径 cable diameter mm | 计算腰量 Approx weight kg/km | 規格 Size mm' | 电缆外径 cable diameter mm | 计算重It Approx weight kg/km |
2x0.75 | 8.8±0.8 | 116 | 2x1 | 9.4 ±0.8 | 112 |
3x0.75 | 9.2±0.8 | 137 | 3x1 | 10.0±1.0 | 136 |
4x0.75 | 9.9±0.8 | 167 | 4x1 | 11.0*1.0 | 169 |
5x0.75 | 10.7±1.0 | 188 | 5x1 | 11.9±1-0 | 193 |
7x0.75 | 11.5±1.0 | 230 | 7x1 | 12.9±10 | 271 |
10x0.75 | 14.8±1.0 | 362 | 10x1 | 16.8±10 | 390 |
12x0.75 | 15.2±1.0 | 399 | 12x1 | 17.210 | 435 |
14x0.75 | 15.9±1.0 | 430 | 14x1 | 18.1±1.0 | 470 |
16x0.75 | 16.7±1.0 | 475 | 16x1 | 19.2±1.0 | 522 |
19x0.75 | 17.5±1.0 | 547 | 19x1 | 20.2±1.5 | 609 |
24x0.75 | 20.3±1.5 | 682 | 24x1 | 23.6±1.5 | 762 |
27x0.75 | 20.7±1.5 | 717 | 27x1 | 24.2±15 | 805 |
30x0.75 | 21.4± 1.5 | 776 | 30x1 | 25.1 ±1.5 | 875 |
33x0.75 | 22.2± 1.5 | 854 | 33x1 | 25.7±1.5 | 968 |
37x0.75 | 23.0±1.5 | 930 | 37x1 | 27.2±15 | 1059 |
2x1.5 | 9.8 ±1.0 | 130 | 2x2.5 | 10.9*1.0 | 164 |
3x1.5 | 10.4±1.0 | 160 | 3x2.5 | 11.6±1.0 | 212 |
4x1.5 | 11.5±1.0 | 195 | 4x2.5 | 12.6±1.0 | 284 |
5x1.5 | 12.4± 1.0 | 260 | 5x2.5 | 14.2±1.0 | 347 |
7x1.5 | 13.9± 1.0 | 334 | 7x2.5 | 15.3±1.0 | 436 |
10x1.5 | 17.5±1.0 | 466 | 10x2.5 | 19.6±1.0 | 595 |
12x1.5 | 18.0±1.0 | 508 | 12x2.5 | 20.2±1.5 | 675 |
14x1.5 | 19.1 ±1.0 | 570 | 14x2.5 | 21.4±1.5 | 780 |
16x1.5 | 20.0 ±1.5 | 651 | 16x2.5 | 22.5±1.5 | 871 |
19x1.5 | 21.3±1.5 | 741 | 19x2.5 | 23.9±1.5 | 978 |
24x1.5 | 24.8 ± 1.5 | 909 | 24x2.5 | 27.9±1.5 | 1232 |
27x1.5 | 25.4 ±1.5 | 989 | 27x2.5 | 28.5±1.5 | 1371 |
30x1.5 | 26.4 ±1.5 | 1100 | 30x2.5 | 29.7±1.5 | 1497 |
33x1.5 | 27.1 ±1.5 | 1192 | 33x2.5 | 30.6±1.5 | 1601 |
37x1.5 | 28.4 ±1.5 | 1284 | 37x2.5 | 32.2±1.5 | 1764 |
