规格 | 电缆外径 | 计算京量 | 规格 | 电缆外径 | 计算重量 |
Size | cable diameter | Approx weight | Size | cable diameter | Approx weight |
mm' | mm | kg/km | mm' | mm | kg/km |
2x0.75 | 7.5t0.8 | 93 | 2x1 | 8.7 ±。8 | 99 |
3x0.75 | 7.8±0.8 | 111 | 3x1 | 9.1 ±。・8 | 126 |
4x0.75 | 8.3±0.8 | 135 | 4x1 | 9.9 ±0 8 | 155 |
5x0.75 | 8.9±0.8 | 152 | 5x1 | 10.7±1。 | 176 |
7x0.75 | 9.5±0.8 | 187 | 7x1 | 11.711-0 | 218 |
10x0.75 | 11.6±1.0 | 264 | 10x1 | 15.0*10 | 350 |
12x0.75 | 12.0±1.0 | 294 | 12x1 | 15.4±10 | 389 |
14x0.75 | 12.51.0 | 322 | 14x1 | 16.3* 10 | 420 |
16x0.75 | 13.6±1.0 | 387 | 16x1 | 17.1±10 | 466 |
19x0.75 | 14.3*1.0 | 446 | 19x1 | 18.0*10 | 542 |
24x0.75 | 16.3±1.0 | 553 | 24x1 | 21.0±1.5 | 675 |
27x0.75 | 16.7±1.0 | 585 | 27x1 | 21.6±1.5 | 713 |
30x0.75 | 17.2±1.0 | 633 | 30x1 | 22.3±1.5 | 774 |
33x0.75 | 17.8± 1.0 | 697 | 33x1 | 22.9±1.5 | 856 |
37x0.75 | 18.4±1.0 | 761 | 37x1 | 24.2115 | 936 |
2x1.5 | 9.1 ±0.8 | 116 | 2x2.5 | 10.1±1.0 | 149 |
3x1.5 | 9.5 ±0.8 | 149 | 3x2.5 | 10.8110 | 199 |
4x1.5 | 10.3±1.0 | 180 | 4x2.5 | 11.7±1.0 | 237 |
5x1.5 | 11.3±1.0 | 212 | 5x2.5 | 12.6±10 | 323 |
7x1.5 | 12.2±1.0 | 306 | 7x2.5 | 14.1±10 | 404 |
10x1.5 | 15.9±1.0 | 423 | 10x2.5 | 17.8110 | 550 |
12x1.5 | 16,3 — 0 | 461 | 12x2.5 | 18.511.0 | 623 |
14x1.5 | 17.1 ±1.0 | 516 | 14x2.5 | 19.411.0 | 718 |
16x1.5 | 18.0±1.0 | 589 | 16x2.5 | 20.4±1.5 | 802 |
19x1.5 | 19.1 ±1.0 | 670 | 19x2.5 | 21.7±15 | 900 |
24x1.5 | 22.2 ±1.5 | 819 | 24x2.5 | 25.3±1.5 | 1131 |
27x1.5 | 22.7 ±1.5 | 890 | 27x2.5 | 25.8±1.5 | 1258 |
30x1.5 | 23.7 ±1.5 | 989 | 30x2.5 | 26.9±1.5 | 1373 |
33x1.5 | 24.3±1.5 | 1071 | 33x2.5 | 27.7±1.5 | 1468 |
37x1.5 | 25.4 ± 1.5 | 1154 | 37x2.5 | 29.2±1.5 | 1618 |
